Todas las lineas · Pistón
Todas las lineasMORESA

Pistón

No. parte1041 STD

Especificaciones técnicas

Buje para Perno IncorporadoNo
Cumple o Excede la Especificación OEMSi
Diámetro de Cazuela (mm)87 mm
Diámetro de Cazuela (pulg)3.425 pulg
Diámetro del Cilindro (mm)101.6 mm
Diámetro del Cilindro (pulg)4 pulg
Diámetro Exterior del Perno (mm)23.95 mm
Diámetro Exterior del Perno (pulg)0.943 pulg
Diámetro Nominal del Pistón (mm)101.562 mm
Diámetro Nominal del Pistón (pulg)3.998 pulg
Distancia de Compresión (mm)33.7 mm
Distancia de Compresión (pulg)1.327 pulg
Espesor 1er Anillo de Compresión (mm)1.2 mm
Espesor 1er Anillo de Compresión (pulg)0.04 pulg
Espesor 2do Anillo de Compresión (mm)1.5 mm
Espesor 2do Anillo de Compresión (pulg)0.059 pulg
Espesor Anillo de Aceite (mm)2.5 mm
Espesor Anillo de Aceite (pulg)0.098 pulg
Longitud del Perno (mm)64.3 mm
Longitud del Perno (pulg)2.531 pulg
Lubricante de Ensamble IncluidoNo
Material del AnilloHierro Gris
Material del PernoAcero
Material del PistónAleación de Aluminio
NotaStandard Size. 4in cylinder diameter. Piston head type Dish. 2.531in Piston pin length. 3.425in bowl diameter
PosiciónN / A
Profundidad Cazuela ó Altura Domo (mm)-1.35 mm
Profundidad Cazuela ó Altura Domo (pulg)-0.053 pulg
SobremedidaNo
Tipo de Cabeza de PistónCazuela
Tipo de Ensamble del PernoFlotante
Tipo de FaldaCompleta
Tipo de GradoRegular

Vehículos compatibles con Pistón (1041 STD)

Compatible con 607 versiones · mostrando 100

MarcaModeloSubmodeloAñoMotor
CadillacCTSV20076.0 V 5967 8 LS2 OHV 16
CadillacCTSV20066.0 V 5967 8 LS2 OHV 16
CadillacEscaladeHybrid20136.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid Platinum20136.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid20126.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid Platinum20126.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid20116.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid Platinum20116.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid20106.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid Platinum20106.0 V 5967 8 LZ1 OHV 16
CadillacEscaladeHybrid20096.0 V 5967 8 LFA OHV 16
CadillacEscaladeBase20066.0 V 5967 8 LQ9 OHV 16
CadillacEscaladeBase20056.0 V 5967 8 LQ9 OHV 16
CadillacEscalade ESVBase20066.0 V 5967 8 LQ9 OHV 16
CadillacEscalade ESVBase20056.0 V 5967 8 LQ9 OHV 16
CadillacEscalade EXTBase20066.0 V 5967 8 LQ9 OHV 16
CadillacEscalade EXTBase20056.0 V 5967 8 LQ9 OHV 16
ChevroletAvalancheLT20096.0 V 5967 8 L76 OHV 16
ChevroletAvalancheLTZ20096.0 V 5967 8 L76 OHV 16
ChevroletAvalancheLT20086.0 V 5967 8 L76 OHV 16
ChevroletAvalancheLTZ20086.0 V 5967 8 L76 OHV 16
ChevroletAvalancheLTZ20076.0 V 5967 8 L76 OHV 16
ChevroletAvalancheLT20076.0 V 5967 8 L76 OHV 16
ChevroletCapricePPV20156.0 V 5967 8 L77 OHV 16
ChevroletCapricePPV20146.0 V 5967 8 L77 OHV 16
ChevroletCapricePPV20136.0 V 5967 8 L77 OHV 16
ChevroletCapricePPV20126.0 V 5967 8 L77 OHV 16
ChevroletCapricePPV20116.0 V 5967 8 L77 OHV 16
ChevroletCorvetteBase20076.0 V 5967 8 LS2 OHV 16
ChevroletCorvetteBase20066.0 V 5967 8 LS2 OHV 16
ChevroletCorvetteBase20056.0 V 5967 8 LS2 OHV 16
ChevroletExpress 2500LS20156.0 V 5967 8 LC8 OHV 16
ChevroletExpress 2500LT20156.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20156.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20156.0 V 5967 8 LC8 OHV 16
ChevroletExpress 2500LS20156.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20146.0 V 5967 8 LC8 OHV 16
ChevroletExpress 2500LS20146.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LT20146.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20146.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LS20136.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LT20136.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20136.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20136.0 V 5967 8 LC8 OHV 16
ChevroletExpress 2500Base20126.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20126.0 V 5967 8 LC8 OHV 16
ChevroletExpress 2500LS20126.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LT20126.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20116.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20116.0 V 5967 8 LC8 OHV 16
ChevroletExpress 2500LS20116.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LT20116.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LT20106.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500Base20106.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LS20106.0 V 5967 8 L96 OHV 16
ChevroletExpress 2500LS20096.0 V 5967 8 - OHV 16
ChevroletExpress 2500LT20096.0 V 5967 8 - OHV 16
ChevroletExpress 2500Base20096.0 V 5967 8 - OHV 16
ChevroletExpress 2500Base20086.0 V 5967 8 - OHV 16
ChevroletExpress 2500LS20086.0 V 5967 8 - OHV 16
ChevroletExpress 2500LT20086.0 V 5967 8 - OHV 16
ChevroletExpress 2500Base20076.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 2500LS20076.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 2500LT20076.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 2500Base20066.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 2500LS20066.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 2500LT20066.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 2500Base20056.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 2500LS20056.0 V 5967 8 LQ4 OHV 16
ChevroletExpress 3500Base20156.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20156.0 V 5967 8 LC8 OHV 16
ChevroletExpress 3500LS20156.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LS20156.0 V 5967 8 LC8 OHV 16
ChevroletExpress 3500LT20156.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LT20156.0 V 5967 8 LC8 OHV 16
ChevroletExpress 3500Base20146.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20146.0 V 5967 8 LC8 OHV 16
ChevroletExpress 3500LS20146.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LT20146.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20136.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20136.0 V 5967 8 LC8 OHV 16
ChevroletExpress 3500LS20136.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LT20136.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LT20126.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20126.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20126.0 V 5967 8 LC8 OHV 16
ChevroletExpress 3500LS20126.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LT20116.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20116.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20116.0 V 5967 8 LC8 OHV 16
ChevroletExpress 3500LS20116.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20106.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LS20106.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500LT20106.0 V 5967 8 L96 OHV 16
ChevroletExpress 3500Base20096.0 V 5967 8 - OHV 16
ChevroletExpress 3500LS20096.0 V 5967 8 - OHV 16
ChevroletExpress 3500LT20096.0 V 5967 8 - OHV 16
ChevroletExpress 3500Base20086.0 V 5967 8 - OHV 16
ChevroletExpress 3500LS20086.0 V 5967 8 - OHV 16
ChevroletExpress 3500LT20086.0 V 5967 8 - OHV 16
