Pistón

Name: Pistón
Brand: MORESA
SKU: 941 STD

No. parte941 STD

Especificaciones técnicas

Buje para Perno IncorporadoNo

Cumple o Excede la Especificación OEMSi

Diámetro de Cazuela (mm)54.86 mm

Diámetro de Cazuela (pulg)2.159 pulg

Diámetro del Cilindro (mm)81 mm

Diámetro del Cilindro (pulg)3.188 pulg

Diámetro Exterior del Perno (mm)20 mm

Diámetro Exterior del Perno (pulg)0.787 pulg

Diámetro Nominal del Pistón (mm)80.96 mm

Diámetro Nominal del Pistón (pulg)3.187 pulg

Distancia de Compresión (mm)32.2 mm

Distancia de Compresión (pulg)1.268 pulg

Espesor 1er Anillo de Compresión (mm)1.2 mm

Espesor 1er Anillo de Compresión (pulg)0.04 pulg

Espesor 2do Anillo de Compresión (mm)1.5 mm

Espesor 2do Anillo de Compresión (pulg)0.059 pulg

Espesor Anillo de Aceite (mm)2 mm

Espesor Anillo de Aceite (pulg)0.078 pulg

Longitud del Perno (mm)56.6 mm

Longitud del Perno (pulg)2.228 pulg

Lubricante de Ensamble IncluidoNo

Material del AnilloHierro Gris

Material del PernoAcero

Material del PistónAleación de Aluminio

NotaStandard Size. 3.188in cylinder diameter. Piston head type Dish. 2.228in Piston pin length. 2.159in bowl diameter

PosiciónN / A

Profundidad Cazuela ó Altura Domo (mm)-3.70 mm

Profundidad Cazuela ó Altura Domo (pulg)-0.146 pulg

SobremedidaNo

Tipo de Cabeza de PistónCazuela

Tipo de Ensamble del PernoFlotante

Tipo de FaldaCompleta

Tipo de GradoRegular

Vehículos compatibles con Pistón (941 STD)

Compatible con 81 versiones

Marca	Modelo	Submodelo	Año	Motor
Volkswagen	Derby	Base	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Derby	MI	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Derby	Base	2008	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Derby	MI	2008	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Derby	Base	2007	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Base	2006	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Base	2005	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Base	2004	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	MI	2003	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Wolfsburg Edition	2002	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Base	2001	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Base	2000	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Base	1999	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Base	1998	1.8 L 1781 4 - SOHC 8
Volkswagen	Derby	Atlanta	1997	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Base	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer	GT	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer	GT BT	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer	Trendline	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer	Base	2008	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer	GT	2008	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer	Trendline	2008	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer	Base	2007	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Trendline	2007	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Base	2006	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Trendline	2006	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline Lujo	2005	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	MI	2005	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	City	2005	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline	2005	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline Lujo	2004	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	MI	2004	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	City	2004	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline	2004	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline Lujo	2003	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	MI	2003	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	City	2003	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline	2003	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Wolfsburg Edition	2002	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	City	2002	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline	2002	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfortline Lujo	2002	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Trendline	2002	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Base	2001	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfort	2001	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Estilo	2001	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Lujo	2001	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Lujo	2000	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Base	2000	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Comfort	2000	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Estilo	2000	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Base	1999	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer	Base	1998	1.8 L 1781 4 - SOHC 8
Volkswagen	Pointer Truck	Base	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Trendline	2009	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Base	2008	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Trendline	2008	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Base	2007	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Trendline	2007	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Base	2006	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Trendline	2006	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline	2005	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline Lujo	2005	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline	2004	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline Lujo	2004	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline	2003	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline Lujo	2003	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline	2002	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Comfortline Lujo	2002	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Trendline	2002	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Wolfsburg Edition	2002	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Confort	2001	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Estilo	2001	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Lujo	2001	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Base	2001	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Base	2000	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Base	1999	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Pointer Truck	Base	1998	1.8 L 1781 4 EA827 SOHC 8
Volkswagen	Van	Base	2005	1.8 L 1781 4 - SOHC 8
Volkswagen	Van	Base	2004	1.8 L 1781 4 - SOHC 8
Volkswagen	Van	Base	2003	1.8 L 1781 4 - SOHC 8
